| Siseosa | GMV-ND45PLS/A-T | GMV-ND50PLS/A-T | GMV-ND56PLS/A-T | GMV-ND63PLS/A-T | GMV-ND71PLS/A-T | GMV-ND80PLS/A-T | |
| Jahutusvõimsus | kW | 4,5 | 5,0 | 5,6 | 6,3 | 7,1 | 8,0 |
| Küttevõimsus | kW | 5,0 | 5,6 | 6,3 | 7,1 | 8,0 | 9,0 |
| Toide | V / ~f / Hz | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 |
| Mootori võimsus | W | 60 | 60 | 60 | 60 | 60 | 60 |
| Õhuvool
(maks./keskm./min.) |
m³/h | 700 / 600 / 450 | 700 / 600 / 450 | 1 000 / 800 / 600 | 1 000 / 800 / 600 | 1 000 / 800 / 600 | 1 100 / 1 000 / 800 |
| Staatiline rõhk | Pa | 15 / 30 | 15 / 30 | 15 / 30 | 15 / 30 | 30 / 50 | 30 / 50 |
| Müratase
(maks./keskm./min.) |
dB(A) | 33 / 31 / 28 | 33 / 31 / 28 | 35 / 33 / 30 | 35 / 33 / 30 | 35 / 33 / 30 | 36 / 34 / 31 |
| Mõõdud (KxLxS) | mm | 200x900x615 | 200x900x615 | 200×1 100×615 | 200×1 100×615 | 260×1 200×655 | 260×1 200×655 |
| Kaal | kg | 27 | 27 | 31 | 31 | 40 | 40 |
| Torustik (Õli+ Gaas) | tolli | 1 / 4 + 1 / 2 | 1 / 4 + 1 / 2 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 |
| Siseosa | GMV-ND90PLS/A-T | GMV-ND100PLS/A-T | GMV-ND112PLS/A-T | GMV-ND125PLS/A-T | GMV-ND140PLS/A-T | |
| Jahutusvõimsus | kW | 9,0 | 10,0 | 11,2 | 12,5 | 14,0 |
| Küttevõimsus | kW | 10,0 | 11,2 | 12,5 | 14,0 | 16,0 |
| Toide | V / ~f / Hz | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 |
| Mootori võimsus | W | 150 | 150 | 150 | 150 | 150 |
| Õhuvool
(maks./keskm./min.) |
m³/h | 1500 / 1 250 / 950 | 1 500 / 1 350 / 10 00 | 1 700 / 1 500 / 1 100 | 2 000 / 1 500 / 1 150 | 2 000 / 1 500 / 1 150 |
| Staatiline rõhk | Pa | 30 / 50 | 30 / 50 | 30 / 50 | 30 / 50 | 30 / 50 |
| Müratase
(maks./keskm./min.) |
dB(A) | 40 / 36 / 32 | 40 / 36 / 32 | 40 / 36 / 32 | 42 / 40 / 37 | 42 / 40 / 37 |
| Mõõdud (KxLxS) | mm | 260×1 340×655 | 260×1 340×655 | 260×1 340×655 | 260×1 340×655 | 260×1 340×655 |
| Kaal | kg | 46 | 46 | 46 | 47 | 47 |
| Torustik (Õli+ Gaas) | tolli | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 | 3 / 8 + 5 / 8 |
| Siseosa | GMV-ND22PLS/A-T | GMV-ND25PLS/A-T | GMV-ND28PLS/A-T | GMV-ND32PLS/A-T | GMV-ND36PLS/A-T | GMV-ND40PLS/A-T | |
| Jahutusvõimsus | kW | 2,2 | 2,5 | 2,8 | 3,2 | 3,6 | 4,0 |
| Küttevõimsus | kW | 2,5 | 2,8 | 3,2 | 3,6 | 4,0 | 4,5 |
| Toide | V/ ~f / Hz | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 | 220-1-50 |
| Mootori võimsus | W | 60 | 60 | 60 | 60 | 60 | 60 |
| Õhuvool
(maks./keskm./min.) |
m³/h | 450 / 350 / 250 | 450 / 350 / 250 | 450 / 350 / 250 | 550 / 450 / 350 | 550 / 450 / 350 | 700 / 600 / 450 |
| Staatiline rõhk | Pa | 15 / 30 | 15 / 30 | 15 / 30 | 15 / 30 | 15 / 30 | 15 / 30 |
| Müratase
(maks./keskm./min.) |
dB(A) | 31 / 28 / 25 | 31 / 28 / 25 | 31 / 28 / 25 | 32 / 30 / 27 | 32 / 30 / 27 | 33 / 31 / 28 |
| Mõõdud (KxLxS) | mm | 200x700x615 | 200x700x615 | 200x700x615 | 200x700x615 | 200x700x615 | 200x900x615 |
| Kaal | kg | 22 | 22 | 22 | 22 | 22 | 27 |
| Torustik (Õli+ Gaas) | tolli | 1 / 4 + 3 / 8 | 1 / 4 + 3 / 8 | 1 / 4 + 3 / 8 | 1 / 4 + 1 / 2 | 1 / 4 + 1 / 2 | 1 / 4 + 1 / 2 |
